FB

Flexible Rubber Power and Control
Food & Beverage

0.6/1kV 90°C
Si
m		 ze
m²		 Min. Bend
Radius mm		 Nom. Cond.
OD mm		 Nom. Ins.
OD mm		 Nom. Cable
OD mm		 Current Rating
amp		 Approx. Wt.
kg/km
1C 6 22 3.2 4.6 7.6 46 99
1C 10 25 4.0 5.6 8.6 64 140
1C 16 28 5.2 6.7 9.8 85 205
1C 25 33 6.3 8.2 11.3 114 290
1C 35 37 7.4 9.4 12.5 141 384
1C 50 42 8.9 10.9 14.0 178 525
1C 70 48 11.0 13.2 16.6 225 750
1C 95 54 12.5 14.7 18.2 271 920
1C 120 62 14.7 17.2 20.8 322 1250
1C 150 69 16.3 19.2 23.1 372 1530
1C 185 76 18.2 21.5 25.6 427 1865
1C 240 84 20.3 23.8 28.0 514 2175
1C 300 92 22.5 26.2 30.6 591 2990
1C 400 105 26.0 30.1 35.0 709 3860
1C 500 117 29.2 33.7 38.9 821 4880
1C 630 130 33.0 37.9 43.4 956 6220
3C 1.5 31 1.6 — 10.4 23 120
3C 2.5 35 2.1 — 11.5 30 160
3C 4 38 2.6 — 12.6 40 210
3C 6 42 3.2 — 13.9 51 280
3C 10 49 4.0 — 16.2 72 400
3C 16 56 5.2 — 18.8 96 596
3C 25 66 6.3 — 22.0 128 846
3C 35 74 7.4 — 24.6 158 1131
3C 50 84 8.9 — 28.0 199 1555
4C 1.5 34 1.6 — 11.2 19 145
4C 2.5 37 2.1 — 12.4 26 200
4C 4 41 2.6 — 13.7 34 265
4C 6 45 3.2 — 15.1 43 350
4C 10 53 4.0 — 17.7 61 511
4C 16 62 5.2 — 20.5 81 770
4C 25 73 6.3 — 24.2 108 1100
4C 35 81 7.4 — 27.0 135 1480
4C 50 84 8.9 — 28.0 170 1555
4C 70 112 11.0 — 37.3 214 2953
4C 95 124 12.5 — 41.4 256 3662
4C 120 143 14.7 — 47.8 303 4990
4C 150 159 16.3 — 53.0 348 6112
4C 185 177 18.2 — 59.0 396 7480
5C 1.5 36 1.6 — 12.1 19 170
5C 2.5 40 2.1 — 13.4 26 235
5C 4 44 2.6 — 14.8 34 316
5C 6 49 3.2 — 16.4 43 425
5C 10 58 4.0 — 19.3 61 626
5C 16 67 5.2 — 22.4 81 950
5C 25 80 6.3 — 26.6 108 1360
5C 35 90 7.4 — 30.0 135 1850
5C 50 103 8.9 — 34.0 170 2560
5C 70 124 11.0 — 41.4 214 3690
5C 95 137 12.5 — 45.8 256 4560
5C 120 159 14.7 — 53.0 303 6210
5C 150 177 16.3 — 59.0 348 7627
5C 185 197 18.2 — 65.5 396 9328
7C 1.5 41 1.6 — 13.4 — 229
7C 2.5 45 2.1 — 14.9 — 320
10C 1.5 50 1.6 — 16.5 — 320
10C 2.5 57 2.1 — 18.8 — 449
12C 1.5 51 1.6 — 17.0 — 363
12C 2.5 58 2.1 — 19.4 — 493
15C 1.5 57 1.6 — 18.7 — 440
15C 2.5 65 2.1 — 21.4 — 625
18C 1.5 60 1.6 — 19.9 — 492
18C 2.5 68 2.1 — 22.5 — 730
21C 1.5 61 1.6 — 20.1 — 581
21C 2.5 72 2.1 — 23.7 — 830
23C 1.5 71 1.6 — 23.4 — 640
23C 2.5 45 2.1 — 25.1 — 901

Continuous current carrying capacities are calculated assuming 40° ambient temperature in free air, flexible unenclosed touching. For other installation methods, please refer to our current ratings table.

Conductor Comparison - TriCab versus Class 5 & 6 (approximate no.of wires)
Size mm²50 70 95 120 150 185 240 300 400 500 630
TriCab658 969 1216 1672 2052 2508 3256 4144 5368 6832 8784
Class5378 342 465 587 734 905 1174 1468 1958 1710 2155
Class6662 927 1258 1589 1987 1401 1817 2272
Issue 19.0
